Wax Lake Bridge Construction Photographs


Held by Special Collections, Linderman Library

Lehigh University, Bethlehem, Pennsylvania 18015

Call No.: SC Photo 0009

1 box, .25 linear feet


wax lake bridge




A collection of construction photographs of a steel railroad bridge erected on a dry flat plain which eventually became a Mississippi River floodway channel. The channel beneath the bridge elements was dredged after the bridge was constructed.   This construction procedure was in reverse of the usual building process. Construction by Bethlehem Steel began in late 1940 and completed in early 1941.  The reverse building process was unusual at the time. The bridge is also known as the Wax Lake Outlet Railway Bridge.  During construction it was also referred to as the Calumet Bridge.


Contact Information:

Special Collections

Linderman Library

Lehigh University

Bethlehem, Pennsylvania 18015, USA

Phone: 610-758 4506

Fax: 610-758 6091



Processed by:

Eleanor Nothelfer



Lehigh University, Linderman Library, Special Collections



Bethlehem Steel Corporation.

The Serice Studio, Franklin, LA.



Wax Lake Bridge construction photographs, 1940-1941


Restrictions to Access:

This collection is open for research.


Preferred Citation:

[Identification of item], Wax Lake Bridge construction photographs, 1940-1941, Special Collections, Linderman Library, Lehigh University, Bethlehem, PA


Copyright Notice

Please inquire about copyright information.


Historical Note:

The Wax Lake Outlet Railway Bridge, located near Calumet, Louisiana, was a unique railroad bridge construction job.  The bridge was built before the canal   that it crosses was dug, in reverse of the usual construction procedure.  The 1340-ft. steel railroad bridge was built across a level stretch of dry land as this collection of photographs indicates.  Later, when the bridge was finished, a canal was dug under the structure.   The canal, a part of the Morganza Floodway, carries Mississippi River flood waters to the Gulf of Mexico. The Wax Lake Bridge was built to serve the Texas and New Orleans Railroad Company (a subsidiary of the Southern Pacific Company).  Modjeski and Masters, bridge engineers, did the design and construction supervision.  Bethlehem Steel Company manufactured the structural members and erected the bridge. The design was completed in 1939 and construction occurred from late 1940 to early 1941.  The bridge won an American Institute of Steel Construction Honorable Mention, Class B, for bridges in 1941.  The channel was dug by the McWilliams Dredging Co.



Engineering News-Record, July 17, 1941, p. 105.



Scope and Content Note:

The collection consists of 104 black and white photographs, mostly 4” x 5”, but some as large as 8” x 10” and as small as 2 ¾” x 4 ½,” originally mounted in a photo album but now stored in Mylar sleeves.  Most photos were coded with an alpha-numeric number and date written on the album page as well as on the back of the photograph.  Many of the photos are marked on the back “The Serice Studio Franklin, La.”  The time span noted for the photographs is from December 31, 1940 to March 20, 1941.  The subject matter is construction photographs of railroad bridge construction built with Bethlehem Steel Co. structural steel members across Wax Lake, St. Mary’s Parish, near Calumet, Louisiana.


Organization of the Content:

The collection of 104 photographs is arranged mostly chronologically beginning December 31, 1940 and ending March 20, 1941.



Indexing Terms

Corporate Subjects:

Bethlehem Steel Company.

Calumet Bridge.

Modjeski and Masters Engineers.

Morganza Floodway.

Texas and New Orleans Railroad.

Wax Lake Bridge.

Wax Lake Outlet Railway Bridge.

The Serice Studio, Franklin, La.


Topical subjects:

Flood control--Mississippi River.

Railroad bridges--Louisiana--Construction.
